WRAPPING MACHINE
Cellophane Wrapping Machine
Outline:
This machine is widely applicable to the automatic film packaging (with gold tear tape) of various single boxed articles, such as the medicine, health products, foodstuff, daily cosmetics, stationery articles, and audiovisual products.
Features
1.No need to regulate the height of two work tops of the machine when the mould is replaced, no need to assemble or dismantle the material discharge chains and discharge hopper. Reduce the replacement time of the mould four hours to the present 30 minutes.
2.New-type double safeguard mechanisms are used, hence other spare parts will not be damaged when the machine runs out of step without the stop of the machine.
3.Original unilateral hand swing device to prevent from shaking the machine adversely, and the non-rotation of the handwheel during the running of the machine can secure the security of the operator.
4.New-type double-rotary film cutting cutter can ensure no need to mill the blade during many-year use of the machine, which overcomes the defect that the traditional stationary single-rotary film cutting cutter was easily worn.
Specification:
Packing Material | BOPP film and gold tear tape |
Packing Speed | 40~80 packs/min |
Packing Size | (L)240×(W)120×(H)60mm |
Electric Supply & Power | 220V 50Hz 5kw |
Weight | 500kg |
Overall Dimensions | (L)2000×(W)700×(H)1400mm |
